La serie Solar Bronze de Solar Gard agrega un cálido acabado de cobre a las ventanas arquitectónicas, armonizando con colores naturales. Estas películas ofrecen rechazo a altas temperaturas y un excelente nivel de privacidad, manteniendo niveles aceptables de luz natural. Añada sofisticación y belleza a su propiedad con Solar Bronze.

Specification Solar-Bronze 20Solar-Bronze 35
Visible light transmittance % 23%31%
Visible light reflectance (exterior) % 36%30%
Visible light reflectance (interior) % 37%30%
Solar heat gain coefficient .25.30
Total solar energy rejected % 75%70%
UV Tdw-ISO @ 300 to 700 nm % 13%18%
UV light blocked (300 to 380 nm) % >99%>99%
Fade Reduction % 84%78%

Performance Notes:

  • Performance results are calculated using NFRC methodology and LBNL Window software, applied to 1/4" (6mm) clear glass and are subject to variations within industry standards and only intended for estimating purposes. This data is provided for informational purposes only and subject to normal manufacturing variances.
  • Performance results for glare and fade reduction are calculated by comparing filmed glass to that of untreated glazing.

Architectural Sample Pages

CSI Specifications: Solar Control Films 08 87 13
