Graffitigard

Solar Gard’s Graffitigard™ protective film is a durable, optically clear and removable product that acts as a sacrificial barrier between vandals and the surfaces they cover.

Key Benefits

  • Can be applied over a wide range of surfaces such as windows, mirrors, stainless steel, marble, and other non-porous surfaces
  • Protects surfaces from paint, key scratches, marking, and even acid-etching
  • Special adhesive allows for easy removal and replacement when vandalised
  • Protects people and property from damaging UV rays
Specification Graffitigard 4milGraffitigard 6milGraffitigard 7mil
Visible light transmittance %86%87%87%
Visible light reflectance (exterior) %10%10%10%
Visible light reflectance (interior) %10%10%10%
Solar heat gain coefficient0.780.780.79
Total solar energy rejected %22%22%21%
UV Tdw-ISO @ 300 to 700 nm %63%62%63%
UV light blocked (300 to 380 nm) %>98%>99%>99%
Fade Reduction %23%24%23%

Performance Notes:

  • Performance results are calculated using NFRC methodology and LBNL Window software, applied to 1/4" (6mm) clear glass and are subject to variations within industry standards and only intended for estimating purposes. This data is provided for informational purposes only and subject to normal manufacturing variances.
  • Performance results for glare and fade reduction are calculated by comparing filmed glass to that of untreated glazing.
