Sentinel Plus OSW Window Film

Solar Gard® Sentinel™ Plus is Solar Gard’s range of exterior window films – which provide maximum heat rejection by being the first line of defense against solar heat and glare. The Sentinel Plus range includes Stainless Steel, Silver, Clear, SX and now also DX (Dual Reflective).

Key Benefits

  • Filming the exterior maximizes heat rejection with up to 82% Total Solar Energy Rejected
  • Provides a refreshed and uniform look to dated buildings
  • Maximum heat rejection also means maximum saving on air conditioning costs
  • UV blockers protect people and property from damaging UV rays

A few references

Film Options and Performance

Product Name Visible Light
Transmittance
Visible Light
Reflectance (Exterior)
UV Light
Blocked
Total Solar
Energy Rejected
Sentinel Plus Silver 20 OSW 16% 61% >99% 82
Sentinel Plus Silver 35 OSW 34% 41% >99% 67
Sentinel Plus Stainless Steel 15 OSW 13% 40% >99% 75
Sentinel Plus Stainless Steel 25 OSW 24% 28% >99% 65
Sentinel Plus Stainless Steel 40 OSW 39% 18% >99% 53
Sentinel Plus SX 50 OSW 48% 27% >99% 56
Sentinel Plus SX 80 OSW 78% 8% >99% 44
Sentinel Plus Solar Bronze 20 OSW 24% 40% >99% 80
Sentinel DX 5 OSW 8% 60% >99 84
Sentinel DX 20 OSW 20% 35% >99 71
Sentinel DX 35 OSW 36% 20% >99 57
Sentinel DX 50 OSW 52% 17% >99 50
Sentinel Silver 20 PC OSW 14% 65% >99 83
Sentinel Plus 4 Mil Clear OSW 89% 10% >99%
Sentinel 8 mil OSW 88% % >99%
Sentinel 4 Mil Clear PC OSW 89% % >99
Performance measured on 1/8” (3mm) thick clear glass.
