Ecolux™ Low-E

Solar Gard’s most advanced product provides year-round comfort improvement by keeping the sun’s heat out in the Summer and keeping heat inside in the Winter.

Key Benefits

  • Low emissivity prevents heat from escaping through windows in the Winter
  • Spectral selectivity lets in 68% of natural light while keeping out 52% of the sun’s energy
  • Money and energy savings year-round on cooling and heating
  • UV blockers protect people and property from damaging UV rays



** This Product is sold exclusively through our Panorama Elite Window Film Network



Specification Ecolux 70
Visible light transmittance % 67%
Visible light reflectance (exterior) % 13%
Visible light reflectance (interior) % 4%
Solar heat gain coefficient .47
Total solar energy rejected % 53%
UV Tdw-ISO @ 300 to 700 nm % 40%
UV light blocked (300 to 380 nm) % >99%
Fade Reduction % 51%

Performance Notes:

  • Performance results are calculated using NFRC methodology and LBNL Window software, applied to 1/4" (6mm) clear glass and are subject to variations within industry standards and only intended for estimating purposes. This data is provided for informational purposes only and subject to normal manufacturing variances.
  • Performance results for glare and fade reduction are calculated by comparing filmed glass to that of untreated glazing.
