Home with Solar Gard Panorama Slate window film installed

Panorama Slate

Slate products are dual reflective – offering increased privacy while maintaining views from the interior.

Key Benefits

  • • Maximized heat rejection for excellent energy savings and payback time
  • Low interior reflectance maintains views to the outside, especially at night
  • High heat rejection results in improved indoor comfort
  • UV blockers protect people and property from damaging UV rays



** This Product is sold exclusively through our Panorama Elite Window Film Network



Panorama Elite Window Film Network and Solar Gard Logo on a transparent background.

Specification Slate 10Slate 20Slate 30Slate 40
Visible light transmittance % 13%23%30%44%
Visible light reflectance (exterior) % 45%31%24%18%
Visible light reflectance (interior) % 23%17%14%12%
Solar heat gain coefficient 0.240.320.380.47
Total solar energy rejected % 76%68%62%53%
UV Tdw-ISO @ 300 to 700 nm % 10%18%23%32%
UV light blocked (300 to 380 nm) % >99%>99%>99%>99%
Fade Reduction % 88%78%72%61%

Performance Notes:

  • Performance results are calculated using NFRC methodology and LBNL Window software, applied to 1/4" (6mm) clear glass and are subject to variations within industry standards and only intended for estimating purposes. This data is provided for informational purposes only and subject to normal manufacturing variances.
  • Performance results for glare and fade reduction are calculated by comparing filmed glass to that of untreated glazing.

CSI Specifications: Solar Control Films 08 87 13
