Clearly see the world beyond your windows with the PureVue™ Ceramic Film Series from Solar Gard. Leveraging one of nature’s most durable elements, this innovative film line boasts significant heat and glare rejection while still maintaining views.

With low reflectance that enhances the natural appearance of glass, PureVue is also optimally suited for demanding coastal environments.

For nature’s clearest views, choose the pure genius of PureVue ceramic technology.

FAST FACTS:

  • Advanced sputtered ceramic technology
    • Rejects up to 58% of total solar energy, resulting in improved indoor climate control and total comfort
  • Low reflectivity
    • Preserves views to the outside, while maintaining the natural look of exterior glass
  • Superior durability
    • Ideal for coastal environments
  • Harmful UV light rejection
    • Protects interior furnishings and finishes from premature fading and sun damage
  • Comprehensive warranty
    • Lasting quality guaranteed for 12 years
Specification PureVue 35PureVue 50PureVue 60PureVue 70
Visible light transmittance % 37%50%61%72%
Visible light reflectance (exterior) % 16%13%11%8%
Visible light reflectance (interior) % 15%11%9%8%
Solar heat gain coefficient .42.52.60.61
Total solar energy rejected % 58%48%40%39%
UV Tdw-ISO @ 300 to 700 nm % 25%33%40%51%
UV light blocked (300 to 380 nm) % >99%>99%>99%>99%
Fade Reduction % 70%60%51%38%

Performance Notes:

  • Performance results are calculated using NFRC methodology and LBNL Window software, applied to 1/4" (6mm) clear glass and are subject to variations within industry standards and only intended for estimating purposes. This data is provided for informational purposes only and subject to normal manufacturing variances.
  • Performance results for glare and fade reduction are calculated by comparing filmed glass to that of untreated glazing.

Architectural Sample Pages

CSI Specifications: Solar Control Films 08 87 13
