Panorama Elite Dealer Network’s solar control safety films are a robust pairing of our exclusive Solar Window films and “Clear Safety” films. These films provide the highest performance in every area of solar comfort; While offering high quality security through a resilient layers of high-tensile polyester and aggressive adhesives for impact resistant security.

Key Benefits

  • Various light transmission ranging from 20-72
  • High heat rejection results in improved indoor comfort
  • UV blockers protect people and property from damaging UV rays



** This Product is sold exclusively through our Panorama Elite Window Film Network



Panorama Elite Window Film Network and Solar Gard Logo on a transparent background.

Specification Hilite 70 8mil
Visible light transmittance %71%
Visible light reflectance (exterior) %9%
Visible light reflectance (interior) %10%
Solar heat gain coefficient.48
Total solar energy rejected %52%
UV Tdw-ISO @ 300 to 700 nm %48%
UV light blocked (300 to 380 nm) %>99%
Fade Reduction %41%

Performance Notes:

  • Performance results are calculated using NFRC methodology and LBNL Window software, applied to 1/4" (6mm) clear glass and are subject to variations within industry standards and only intended for estimating purposes. This data is provided for informational purposes only and subject to normal manufacturing variances.
  • Performance results for glare and fade reduction are calculated by comparing filmed glass to that of untreated glazing.
