Sentinel Plus is Solar Gard’s range of exterior window films – which provide maximum heat rejection by being the first line of defense against solar heat and glare. The Sentinel Plus range includes Stainless Steel, Silver, Clear, and SX.

Key Benefits

  • Filming the exterior maximizes heat rejection with up to 82% Total Solar Energy Rejected
  • Provides a refreshed and uniform look to dated buildings
  • Maximum heat rejection also means maximum saving on air conditioning costs
  • UV blockers protect people and property from damaging UV rays
Specification Sentinel Plus 4mil ClearSentinel Plus 8mil Clear
Visible light transmittance % 88%87%
Visible light reflectance (exterior) % 9%9%
Visible light reflectance (interior) % 9%9%
Solar heat gain coefficient 0.790.79
Total solar energy rejected % 21%21%
UV Tdw-ISO @ 300 to 700 nm % 60%60%
UV light blocked (300 to 380 nm) % >99%>99%
Fade Reduction % 27%60%

Performance Notes:

  • Performance results are calculated using NFRC methodology and LBNL Window software, applied to 1/4" (6mm) clear glass and are subject to variations within industry standards and only intended for estimating purposes. This data is provided for informational purposes only and subject to normal manufacturing variances.
  • Performance results for glare and fade reduction are calculated by comparing filmed glass to that of untreated glazing.

Architectural Sample Pages

Glass Retention

CSI Specifications: Safety and Security Films 08 87 23
