sentinel-plus-qxn-75

Invisible Sun Protection. Powerful Performance.

Sentinel Plus QXN 75 OSW is a next-generation solar control film that delivers exceptional heat rejection while remaining virtually invisible. Designed for modern glazing systems, it enhances comfort, reduces energy costs, and preserves the aesthetics of your space.

  • HIGH HEAT REJECTION – Blocks over 55% of solar energy, keeping interiors cooler and reducing air conditioning costs.
  • CRYSTAL-CLEAR VIEWS – Maintains high visible light transmission (69%) with low reflectance, preserving natural daylight and the original look of your glass.
  • LOW ABSORPTION TECHNOLOGY – Advanced sputtering technology ensures minimal heat absorption, making it suitable for nearly any glazing type—even high-performance glass.
  • UV & IR PROTECTION – Rejects >99% of harmful UV rays and 85% of infrared radiation, helping to protect interiors from fading and damage.
  • 10-YEAR LIMITED MANUFACTURER WARRANTY – Solar Gard offers a 10-year limited manufacturer warranty on Sentinel Plus OSW installations, with QXN 75 available in widths up to 72” for large glass applications.
Specification Sentinel Plus QXN 75
Visible light transmittance % 69%
Visible light reflectance (exterior) % 8%
Visible light reflectance (interior) % 8%
Solar heat gain coefficient 0.42
Total solar energy rejected % 58%
UV Tdw-ISO @ 300 to 700 nm % 45%
UV light blocked (300 to 380 nm) % >99%
Fade Reduction % 45%

Performance Notes:

  • Performance results are calculated using NFRC methodology and LBNL Window software, applied to 1/4" (6mm) clear glass and are subject to variations within industry standards and only intended for estimating purposes. This data is provided for informational purposes only and subject to normal manufacturing variances.
  • Performance results for glare and fade reduction are calculated by comparing filmed glass to that of untreated glazing.

CSI Specifications: Safety and Security Films 08 87 23
